X Series Tedders
The 46X is a premium tedder at a value price. This tedder was designed with the essential features people love about Pequea’s tedders: large tires for smooth field travel and fewer flats and real 4 bolt hubs with tapered bearing that last longer and allow for faster travel. The 46X has six flat bar tine arms per rotor and with asymmetrical tines on each arm. Heavy enclosed oil-bath commercial gearboxes are driven by a hexagonal shaft. At the pivot points, power is transferred through forged steel, carbo-austempered finger drives. Hydraulic fold and tilt are also standard, so there is to leave the tractor until the job is done.
|Transport Width||8′ 11″|
|Overall Length||9′ 8″|
|Number of Rotors||4|
|Tine Arms per Rotor||6|
|Rotor Tire||18.5 x 8|
|Hydraulic Requirement||1,600 psi|
|PTO Power Requirement||30 hp|
|Rotor Gearbox||Enclosed Grease|
|Center Gearbox||Oil Bath|
|Tine Arm Material||.5 inch Steel Flatbar|
|Rotor Spindle Wheel Hub||4-Bolt with Tapered Bearings|
- Power is transferred through the pivots by forged, carbo-austempered finger drives that stay engaged when the tedder is folded for transport.
- Each rotor is supported by 18.5 x 8″ implement Tired and real 4 bolt hubs with tapered bearings.
- Hydraulic is standard on the 46X, like all Pequea Rotary Tedders, to create tine clearance on the go. A threaded rod on the cylinder allows for finetuned adjustment.
- The 46X uses high-strength flat bar tine arms to hold six asymmetrical tines on each rotor.
