Litter/Lime Spreaders

SP550

The Pequea SP Series Spreaders are offered in 16′, 18′, 20′, and 22′ hopper lengths, the SP spreaders bring up to 580 cubic foot hauling capacity along with easy-to-use flow control valves for the apron and spinner speeds. With over 15 different options available including a truck mount configuration, the SP Series is highly adaptable to any environment.

SP550 Litter Poultry Spreader Equipment

Specifications

Hopper Length          22′
Hopper Width (Top) 96″
Overall Height 91″
Overall Length 32′
Overall Width 99″
Struck Capacity 450 cu. ft.
Heaped Capacity 580 cu. ft.
Payload 27,000 lb
Empty Weight    6,600 lb
Chain Width 35″
Heavy Duty Tandem Axle Standard
Sight Window Standard
Floor 3/4″ x 6″ Tongue and Groove Poly Floor
Chain       Heavy Duty 88K
Spinner Disc Diameter 25″
Spinner Disc Thickness 1/4″
Spinner Paddles  6 Bolt on Reinforced
Adjustable Spinners and Spinner Frame     Standard





Features

  • Truck mount or tandem axle configurations
  • Hydraulic flow controls for quick, fine-tuned adjustment of floor and spinner speeds
  • Heavy duty 88k floor chain runs on lifetime poly tongue and groove flooring
  • Heavy duty 25″ spinner discs ensure a smooth and consistent spread pattern

Manuals

pdf-icon

Litter Spreader Ops Manual

pdf-icon

Litter Spreader Parts101420

pdf-icon

LitterSpreader_SS_lo - Copy

Rate Chart

SP Series Rate Chart

Enter the following values for the estimated spread rate
